With every project, you need to capture that perfect vocal and make the sound your own. VoiceMaster Pro represents a new generation of voice recording equipment.

Many of the elements from the award-winning VoiceMaster have been innovated upon. In addition, the unit features a whole host of new processors designed to ensure you have all you require to make the most of the artist you’re recording.

The award-winning Class A preamp captures every nuance from any source, whilst latency-free monitoring ensures direct and delay-free mix control. Tools such as the voice-optimised EQ, Vintage Harmonics and Tube Sound allow you to get creative with a touch of class, putting your own stamp on every recording.

All of this, combined with the optional 24 bit, 96 kHz digital output board means that VoiceMaster Pro is the perfect interface between your microphone and your DAW or other recording media, placing the ultimate tracking solution firmly within your grasp.

MIC INPUT RESPONSE
- Gain range = 0 dB to 60 dB continuously variable
- Input Impedance = 1K4 Ù from 10 Hz to 200 kHz
- EIN = 128 dB measured at 60 dB of gain with 150 Ù terminating impedance and 20 Hz/22 kHz bandpass filter
- THD at minimum gain (0 dB) = 0.0004% measured with +16 dBu input signal and with a 20 Hz/22 kHz bandpass filter
- THD at maximum gain (60 dB) = 0.003% measured with a –36 dBu input signal and with a 20 Hz/22 kHz bandpass filter
- THD at maximum input level (26.5 dBu) = 0.005% measured with a 20 Hz/22 kHz bandpass filter
- Frequency response at minimum gain (0 dB) = flat at 10 Hz and –2 dB down at 200 kHz
- Frequency response at maximum gain (60 dB) = –2 dB down at 10 Hz and 200 kHz
- CMRR at full gain (60 dB) = 80 dB

LINE INPUT RESPONSE
- Gain range = -10 dB to +10 dB continuously variable
- Input Impedance = 10K Ù from 10 Hz to 200 kHz
- Noise at main output with gain and fader set to unity (0 dB) = -94 dBu measured with a 20 Hz/22 kHz bandpass filter
- Signal to noise ratio relative to max headroom (27 dBu) = 121 dB
- Signal to noise ratio relative to 0 dBfs (+22 dBu) = 116 dB
- THD at unity gain (0 dB) = 0.0006% measured with 0 dBfs (+22 dBu) input signal and with a 20 Hz/22 kHz bandpass filter
- Frequency response at unity gain (0 dB) = 0.25 dB down at 10 Hz and –3 dB down at 200 kHz

INSTRUMENT INPUT RESPONSE
- Gain range = 0 dB to 40dB continuously variable
- Input Impedance = > 1 Meg Ù
- Noise at minimum gain (0 dB) = -90 dBu measured with a 20 Hz/22 kHz bandpass filter
- Noise at maximum gain (40 dB) = -78 dBu measured with a 20 Hz/22 kHz bandpass filter
- THD at minimum gain (0 dB) = 0.006% measured with –10 dBu input signal and with a 20 Hz/22 kHz bandpass filter
- Frequency response at unity gain (0 dB) = 0.5 dB down at 10 Hz and –1 dB down at 200 kHz
- Frequency response at maximum gain (40 dB) = 6 dB down at 10Hz and –1dB down at 200KHz
