Chauvet DJ Q-Spot™ 260-LED

High Power Moving Yoke w/ 60W White LED

Product Code 65085

Retail Price
$1429.99
Sale Price!
$849.99
Buy Today and Save $580.00 (41% from Retail)

Add to Cart

This Item Ships FREE!
Click for Details
Click Here For Shipping Options

8thstreet Reward$
Found a Lower Price?
Call 1-800-878-8882
Click here to let us know now!

Manufacturer
Chauvet DJ

The Q-Spot™ 260-LED is a high power moving yoke equipped with a 60-watt white LED. It includes a color wheel with eight slots plus white and two gobo wheels, one with seven rotating slot-n-lock gobos plus open and the other with nine fixed gobos plus open. The easy-access hatch provides for tool-free gobo changes. It also includes remote focus and a rotating prism.



MPN QSpot260LED 0 0

Item Number
QSpot260LED

  • DMX channels: DMX channels: 11 or 14
  • Pan: 540°
  • Tilt: 270°
  • Colors Wheel: 8, continuous scroll at variable speeds
  • Gobo wheel (static): 9, interchangeable, continuous scroll at variable speeds
  • Gobo wheel (rotating): 7 (5 metal + 2 glass), interchangeable, slot-n-lock, continuous scroll at variable
  • 3-facet rotating prism
  • Variable electronic dimmer (0 ~ 100%)
  • Remote fixture reset
  • Move-in-black for pan/tilt
  • Built-in automated programs
  • Built-in sound activated programs
  • 255 user-programmable steps without DMX controller
  • High-powered, 60 W LED
  • User-selectable pan/tilt ranges
  • Automatic pan/tilt correction
  • Reset to factory settings option
  • User-selectable basic or advanced operating modes
  • Easy access door for gobo change
  • DMX connectors: 3-pin
  • Pan & tilt: 540° / 270°
  • Gobo size: 26mm outside, 19mm image, 2.2mm max thickness
  • Source: 60 W LED, 50,000 hours
  • Configuration: 1 white (12.6 A)
  • Beam angle: 15°
  • Lux: 750 @ 5 m
  • AC Voltage Range: 100~240 V, 50/60 Hz (auto-ranging)
  • Power Consumption 120 V, 60 Hz: 153 W, 1.3 A (operating)
  • Power Consumption 230 V, 50 Hz: 138 W, 0.6 A (operating)
  • Dimensions: 11.4 x 10.9 x 19.1 in (292 x 278 x 485 mm)
  • Weight: 30 lbs (13.6 kg)
  • Gobo Size: 25.8 mm outside, 18.2 mm image, 1.2 mm max thickness
  • Power Connection: IEC
  • Control Connection: 3-pin DMX
  • Certification: CE, ETLc
  • Environment: IP20, dry location
