AUDIENCE CONNECTION LIKE NEVER BEFORE
Every single detail you need to make your song exceptional – every FX change, every harmony, every loop – every sonic nuance – can be prepared on VL3X before the show. This totally transforms your relationship to the audience. (Oh, and did we say that you can do all of this for over 100 songs?)

RECORDING & SHARING POWER
Your inspired backing tracks and FX sequencing are beautifully matched by the onboard audio recorder that allows you to capture everything you do in glorious 24-bit quality. Record every live performance, every home practice, with professional studio fidelity and effects – both vocal and guitar. Turn your tour into EP material or your late night jams into SoundCloud gold.

YOUR VOICE: FRONT & CENTER
With a mind-blowing vocal FX path featuring 11 independent effects blocks, over 180 different pre-programmed styles and more than 250 factory presets available right out of the box (and more available for free download), VL3X represents the absolute pinnacle of singers' technology and is the perfect partner for your voice.

NO COMPROMISE GUITAR FX & AMP TONES
The guitar section of VL3X puts a premium stomp box collection at your feet – with rich tones from legendary FX makers TC Electronic – plus 30 amp emulations that can be customized far beyond belief. Together they make up an unbeatable piece of guitar road-kit.

BUILDING BETTER SONGS WITH LOOPS
Featuring 4 times the storage of VoiceLive 3, VL3X enables you to store every loop snippet or idea you have, allowing you to experiment with real-time song creation and exciting loop jams right until you drop. The smart LoopAssist™ and metronome functions help you to make tighter loops effortlessly and auto-expand allowing for different loop lengths.

DEDICATED VOCAL PA AND GUITAR OUT
What makes VL3X an incredibly flexible performance system is the dedicated stereo vocal and stereo guitar amp outputs. Send your guitar sound directly to your favorite amp completely independent of the vocal output going to the PA – it even works when you're looping.

MPN: 996354105
UPC: 5706622021823

• NEW! Backing track import with FX automation for "tap-dance free" performances, synchronized to tracks

• NEW! Performance recorder for live direct 24-bit audio, output to a USB flash drive

• A complete vocal sound with next generation harmony processing, effects and tonal quality

• Complete guitar sound via TC Electronic stomp box effects, Amp Tones and flexible outputs to your amp or PA

• Powerful 3-phrase looping lets you create and store entire songs on-the-fly

  VOCAL EFFECTS

• µMod

• Echo & Delay

• Reverb

• Harmony

• Double

• Transducer

• Rhythmic

• HardTune & Correction

• Choir

• Stutter

• Vocoder

• Adaptive Tone

  GUITAR FX

• Amp Modeling

• Drive

• Delay

• Reverb

• Compression

• Resonant Filter

• Wah

• µMod (Flange, Chorus, De-tune)

• Shifter

• Rhythmic/Tremolo

• Talkbox (part of Vocoder)

  CONTROL

• 250 factory presets

• Memory for 500 presets

• 10 steps per preset

• 10 footswitches

• 6 preset-assignable footswitches for enabling/disabling FX blocks

• Backing track & FX automation control via footswitches

• Detailed editing

• Genre and Styles preset categories

  SIZE

• Height: 3 inches (76 mm)

• Width: 13.8 inches (350 mm)

• Depth: 8.5 inches (216 mm)

  WEIGHT

• Weight: 5 lb. (2.3 kg)

  CONSTRUCTION

• Anodized extruded aluminum and steel chassis

• Rubberized edit/mix knobs

• Recessed rubberized handle

• 192 x 64 Blue STN LCD, White Back light display

• Tri-colored Footswitch Light ring

• Capacitive touch edit controls with LED indicators

  ANALOG INPUTS

• Voice

• Connector: Combo Balanced XLR/Balanced TRS 1/4″ phone jack

• Input Impedance Balanced: 3.08 kOhm

• Mic Input Level @ 0 dBFS: -52 dBu to +7 dBu

• Line Input Level @0dBFS: -40 dBu to +19 dBu

• EIN @ Max Mic Gain Rg = 150 Ohm: -127 dBu

• Mic SNR >100 dB at typical Mic Input gain

• Phantom Power: +48V (on/off via setup menu)

• A to D Conversion 24 Bit, 128 x oversampling bitstream, 110 dB SNR A-weighted

  Guitar

• Connector: 1/4″ phone jack

• Guitar Input Impedance: 1 MOhm

• Guitar Input Level @ 0 dBFS: -2 dBU to 14 dBu

• Guitar Input SNR >108 dB

• A to D Conversion 24 Bit, 128 x oversampling bitstream, 110 dB SNR A-weighted

  Monitor

• Connector: Balanced XLR

• Input Impedance Balanced: 25 kOhm

• Monitor Input Level @ 0 dBFS +16 dBu

  Aux

• Aux: 1/8″ stereo mini jack

• Aux Input Level @ 0 dBFS +2 dBu

  ANALOG OUTPUT

• Voice

• Connectors: balanced XLR

• Output Impedance Balanced/Unbalanced: 300/150 Ohm

• Output Range 0 dBFS Line Level: +14 dBu; Mic Level: – 2dBu

• Dynamic Range >109 dB, 20 Hz to 20 kHz/li>

• Frequency Response +0/-0.3 dB, 20 Hz to 20 kHz

• D to A Conversion 24 Bit, 128 x oversampling bitstream, 115 dB SNR A-weighted

  Guitar

• Connectors: 1/4″ TRS phone jack

• Output Impedance Balanced/Unbalanced: 442/221 Ohm

• Output Range 0 dBFS Line Level: +14 dBu; Mic Level: – 2dBu

• Dynamic Range >105 dB, 20 Hz to 20 kHz note

• D to A Conversion 24 Bit, 128 x oversampling bitstream, 106 dB SNR A-weighted

  Headphone

• 1/8″ Mini stereo jack, 50 Ohm, +14 dBu max

  Guitar thru

• Buffered Guitar Input

• Connector: 1/4″ TRS phone jack

• Output Impedance Bal/UnBal: 270/540 Ohms

  Monitor thru

• Direct connection to Monitor input

• Connector: Balanced XLR

  CONTROL

• USB: USB A, Mini-B

• MIDI: In/Out: 5 Pin DIN

• Pedal: 1/4″ TRS phone jack

• Mic Control using TC-Helicon MP-75 Microphone or Sennheiser e 835 fx mic

  POWER

• External Power Supply Mains Voltage: 100 to 240 VAC, 50 to 60 Hz (auto-select)

• Power Consumption: < 14 W

  SAFETY

• EMC – Complies with: EN 55103-1:2009, EN 55103-2:2009,
• FCC CFR 47 Part 15B and ICES-003:2004 4th Ed

• Safety – certified to: IEC 65, EN 60065, UL6500 and CSA IEC 65, EN 60065, UL6500 and CSA

  ENVIRONMENT

• Operating Temperature: 32° F to 122° F (0° C to 50° C)

• Storage Temperature: -22° F to 167° F (-30° C to 70° C)

• Humidity: Max. 90 % non-condensing

  WHAT'S IN THE BOX?

• Region specific power supply

• USB cable

• Quickstart guide

• Guitar/Headphone combo cable
