Shred in ergonomic comfort and style with the Jackson X Series Dinky™ Arch Top DKAF7 MS. A high-performance evolution of the electric guitar, this 7-string multi-scale model unlocks the possibilities of an instrument by accommodating two scale lengths on one fingerboard, thus improving overall playing comfort while improving tension and intonation.

Features a 25.5"-27" multi-scale length, mahogany body with an arched top, one-piece bolt-on maple neck with graphite reinforcement and scarf joint, 12"-16" compound radius dark rosewood fingerboard with 24 jumbo frets and offset dot inlays, Jackson die-cast tuners and AT-1 4x3 (four on top, three on bottom) headstock.

Dual Jackson uncovered 7-string blade humbucking pickups power this metal beast and can be shaped by a three-way toggle switch and volume and tone controls.

To help improve intonation, the guitar has been equipped with Jackson designed individual bridge saddles, staggered to accommodate for the two scale lengths.

Available in Stained Mahogany with black hardware.

MPN: 2916173557
UPC: 885978858309

• Model Name: X Series Dinky™ Arch Top DKAF7 MS,
• Dark Rosewood, Stained Mahogany

• Model Number: 2916173557

• Series: X Series

• MSRP: $816.31

• Color: Stained Mahogany

• Body Shape: Dinky™

• Body Material: Mahogany

• Body Finish: Satin

• Neck Material: 1-Piece Bolt-On Maple Speed Neck with Graphite Reinforcement and Scarf Joint

• Neck Binding: None

• Scale Length: 25.5" - 27" Multi-Scale

• Fingerboard Radius: 12" to 16" Compound Radius (304.8 mm to 406.4 mm)

• Number of Frets: 24

• Fret Size: Jumbo

• String Nut: Black Plastic

• Nut Width: 1.875" (47.6 mm)

• Truss Rod Nut: Truss Rod Adjustment at Nut

• Headstock: Jackson® 4+3 AT-1

• Neck Plate: 4-Bolt (recessed screws)

• Neck Finish: Satin

• Fingerboard: Dark Rosewood

• Position Inlays: Offset dots

• Bridge Pickup: Jackson® uncovered seven string blade humbucker

• Neck Pickup: Jackson® uncovered seven string blade humbucker

• Controls: Volume, Tone

• Pickup Switching: 3-Position Toggle: Position 1. Bridge Pickup, Position 2. Bridge And Neck Pickups, Position 3. Neck Pickup

• Pickup Configuration: H/H

• Bridge: Staggered Individual Saddles

• Tuning Machines: Jackson® Branded

• Orientation: Right-Hand

• Pickguard: None

• Control Knobs: Dome Style

• Strings: NPS, .009-.054 Gauges
