The portable MGX12 compact digital mixing console delivers superb sound quality, intuitive setup, and professional features for live sound, installed systems, streaming, and recording. With a 4.3-inch touchscreen, hands-on controls, flexible I/O, and built-in DSP, the MGX12 is built to move fast in real-world workflows—whether you’re mixing a small band, running a venue, or producing a podcast.

Dual USB connectivity, onboard sound pads, Bluetooth input, and microSD multitrack recording make the MGX12 a compact hub for hybrid workflows—live reinforcement, streaming, and production—while keeping operation simple and repeatable with scene recall and assistive gain tools.

MPN: MGX12B
UPC: 889025170963

• 11 + 1 non-motorized fader configuration for quick hands-on mixing

• 4.3-inch touchscreen with five control knobs for fast, intuitive control

• Input mixing channels: 4 mono + 4 stereo + 1 Sound Pad + 2 FX return

• Busses: 1 stereo + 8 mix

• Local inputs: 4 combo (mic/line), 4 TRS (line), 4 RCA (line)

• Local outputs: 2 XLR, 6 TRS phone, 4 headphone outputs

• USB MAIN: 18-in / 18-out audio interface (32-bit / 96 kHz)

• USB SUB: 2-in / 2-out audio interface (16-bit / 48 kHz)

• microSD card: 16-track recording / 2-track playback (24-bit / up to 96 kHz)

• Bluetooth audio input: 2-channel (Bluetooth 5.0, A2DP)

• Built-in DSP for professional processing and latency-free monitoring

• Assistive tools: Auto Gain, Clip Safe, Simple/Standard mode, Scene Recall

• Input Mixing Channels: 4 mono + 4 stereo + 1 Sound Pad + 2 FX return

• Busses: 1 stereo + 8 mix

• Local Inputs: 4 combo (mic/line); 4 TRS (line); 4 RCA (line)

• Local Outputs: 2 XLR; 6 TRS phone; 4 headphone outputs

• USB MAIN Interface: 18 inputs / 18 outputs (32-bit / 96 kHz)

• USB SUB Interface: 2 inputs / 2 outputs (16-bit / 48 kHz)

• microSD Recording/Playback: 16-track recording / 2-track playback (24-bit)
